Shanling EC Zero T
ETA 3rd week of July
EC Zero T represents a culmination of the latest trends in the portable Hi-Fi market, combining biggest Shanling’s highlight features from the past two years.
Key Features:
In-house developed R2R module, featuring 192 0.1% precision resistors
Non-Oversampling / Oversampling Modes
Dual JAN6418 Tube Output & TPA6120 Headphone Amplifier
Transistor / Tube Mode Output Switching
Offering up to 1220mW @ 32 Ohm Output power
3.5mm & 4.4mm Headphone Outputs
Dedicated 3.5mm & 4.4mm Line-Out
Bluetooth V5.3 output supporting aptX Adaptive, aptX and SBC
Coaxial / Optical SPDIF Output
Active Magnetic CD Clamp
Advanced Anti-Skip system for smooth playback on-the-go
Custom CD Drive and System
USB DAC Function supporting PCM 768 kHz / DSD512
Built-in 5500mAh Battery, up to 8h of playback
USB-C Power input for External Power Mode
Aluminium chassis construction, with tempered glass panels.
1.68-Inch Colour screen with basic Interface
Hardware buttons and Volume slider controls
ETA 3rd week of July
EC Zero T represents a culmination of the latest trends in the portable Hi-Fi market, combining biggest Shanling’s highlight features from the past two years.
Key Features:
In-house developed R2R module, featuring 192 0.1% precision resistors
Non-Oversampling / Oversampling Modes
Dual JAN6418 Tube Output & TPA6120 Headphone Amplifier
Transistor / Tube Mode Output Switching
Offering up to 1220mW @ 32 Ohm Output power
3.5mm & 4.4mm Headphone Outputs
Dedicated 3.5mm & 4.4mm Line-Out
Bluetooth V5.3 output supporting aptX Adaptive, aptX and SBC
Coaxial / Optical SPDIF Output
Active Magnetic CD Clamp
Advanced Anti-Skip system for smooth playback on-the-go
Custom CD Drive and System
USB DAC Function supporting PCM 768 kHz / DSD512
Built-in 5500mAh Battery, up to 8h of playback
USB-C Power input for External Power Mode
Aluminium chassis construction, with tempered glass panels.
1.68-Inch Colour screen with basic Interface
Hardware buttons and Volume slider controls
ETA 3rd week of July
EC Zero T represents a culmination of the latest trends in the portable Hi-Fi market, combining biggest Shanling’s highlight features from the past two years.
Key Features:
In-house developed R2R module, featuring 192 0.1% precision resistors
Non-Oversampling / Oversampling Modes
Dual JAN6418 Tube Output & TPA6120 Headphone Amplifier
Transistor / Tube Mode Output Switching
Offering up to 1220mW @ 32 Ohm Output power
3.5mm & 4.4mm Headphone Outputs
Dedicated 3.5mm & 4.4mm Line-Out
Bluetooth V5.3 output supporting aptX Adaptive, aptX and SBC
Coaxial / Optical SPDIF Output
Active Magnetic CD Clamp
Advanced Anti-Skip system for smooth playback on-the-go
Custom CD Drive and System
USB DAC Function supporting PCM 768 kHz / DSD512
Built-in 5500mAh Battery, up to 8h of playback
USB-C Power input for External Power Mode
Aluminium chassis construction, with tempered glass panels.
1.68-Inch Colour screen with basic Interface
Hardware buttons and Volume slider controls
Specifications
Screen: 1.68-inch LCD display
USB DAC Supports: 768kHz/32bit, DSD512
Bluetooth version: V5.3
Bluetooth transmit support: aptX Adaptive, aptX, SBC
Dimensions: 158 x 150 x 28mm
Weight: about 669g
3.5mm Headphone Output:
Output Power:
Transistor:
Low Gain: 57mW@32Ω
High Gain: 158mW@32Ω
High Gain: 330mW@32Ω (DC power)
Tube:
Low Gain: 47mW@32Ω
High Gain: 158mW@32Ω
High Gain: 268mW@32Ω (DC power)
THD+N: 0.02%
Dynamic Range: 116dB
Channel Separation: 79dB
SNR: 115dB
Noise: 111dB
Output Impedance: 4.7 Ω
4.4mm Headphone Output:
Output Power:
Transistor:
Low Gain: 195mW@32Ω
High Gain: 551mW@32Ω
High Gain: 1220mW@32Ω (DC power)
Tube:
Low Gain: 195mW@32Ω
High Gain: 551mW@32Ω
High Gain: 1087mW@32Ω (DC power)
THD+N: 0.02%
Dynamic Range: 117dB
Channel Separation: 103dB
SNR: 117dB
Noise: 108dB
Output Impedance: 6.6Ω
